Product Description
Electrical
▪ Power supply: Electronic auto-ranging
▪ Power Input Rating: 100-240 V AC, 50-60 Hz
▪ Power consumption: 250W
Optics
▪ Light source: (1) 150W Warm White+Cool White 3,200K-6,400K COB LEDs
▪ Color temp : 3,200K-6,400K
▪ Drive Mode: Constant Current
Color System
▪ Color: Warm White+Cool White
Effects
▪ Strobe: 0-25Hz
▪ Dimming : 0% – 100%
▪ Variable Dimming Curves
Control and Programming
▪ Control Mode: DMX, Auto, Sound-activate,Master-slave
▪ Control Channels: 3/6CH
▪ Display: LED
Connections
▪ Data in/out:fixed cable
▪ Power in/out: fixed cable
Thermal Management
▪ Over temperature protection
▪ Cooling fans intelligent speed regulation
▪ Thermal management system ensures long life of LEDs
Work Enviroment
▪ Maximum ambient temperature (Ta max.): 40° C (104° F)
▪ Minimum ambient temperature (Ta min.): 5° C (41° F)
Safety Devices
▪ Power failure memory
▪ Protection: Overcurrent, overvoltage and overheating
Construction
▪ Housing: aluminium+steel
▪ Color: Black
▪ Housing surface treatment: baking finished treatment
▪ Protection rating: IP65
Mechanical Specification
▪ Length: 152 mm
▪ Width: 185 mm
▪ Height: 265 mm
Weight
▪ Net Weight: 4.0kg
